Ebike Electric Bike Bicycle 24/36/48V/60V Headlight and Tail Light Sets

Application: LED headlights for electric bicycles, shared electric vehicles, and motorcycle Net weight of the whole set: 330g Package weight: about 0.65KG (small carton) Work status description: Driving lights: When the switch of driving lights is turned on, the headlights and tail lights are on Horn: When the horn button is pressed, the horn starts to work, release it to cancel Brake light: When the brake signal line and the controller brake low voltage signal are connected normally, the brake light will light up while braking, and the brake light will go out when the brake is cancelled Turn signal: When the turn switch of the designated direction is toggled, the turn signal of the corresponding direction starts to work and flashes, the flashing frequency is about 800ms each time the data of Headlight 1. Net weight of headlight: 100g 2. Shell material: plastic 3. Applicable voltage range: 24V-60V 4. Power: 59mA/2.8W 5. Luminous flux: 180-220LM 6. Horn Power: 44mA/2.1W 7. Horn Volume: 80-100dB 8. CQC Certification: CQC19134228086 9. Product size: 62*50*70mm 10. Cable length: about 1.5M 11. Light Power: 12W the data of Tail Light The tail lamp includes brake and turn signal（left and right） functions 1. Net weight of taillight: 120g 2. Shell material: plastic 3. Applicable voltage range: 24-80V 4. Power: 1.5W 5. Number of light sources: 14 6. Luminous flux: 15LM 7. Product size: 132*65*40mm 8. CQC certification: CQC19134228085 9. Cable length: about 1.5M
